YongBang Machinery
Film Blowing Machine Manufacturer
The fully automatic ABA blown film machine enables unmanned intelligent production from feeding to winding, ensuring superior film quality while eliminating manual labor and efficiency bottlenecks.
| Film Thickness(mm): | 0.01~0.08 |
| Max. Output(kg/h): | 80/100/120 |
| Film Layer: | 3 |
Our fully automatic ABA blown film machine features an advanced dual-station winding system that enables seamless, continuous production without any downtime. This automated solution requires minimal labor – just one operator can monitor multiple production lines simultaneously. The program-controlled winding ensures consistently high-quality output, while our digital management system provides complete production traceability. This represents a significant advancement over traditional semi-automatic equipment, which typically requires dedicated operators, experiences frequent production stops for winding changes, and produces variable results dependent on worker skill.
| Main motor | Chinese Brand And Siemens |
| Suitable materials | HDPE, LDPE, LLDPE |
| Screw L/D | 32:1 / 30:1 |
| Inverter | Delta Chinese Brand |
| Temperature-controlled meter | Omron |
| Air ring | Double vent air ring |
| Model | YB-700 | YB-900 | YB-1200 |
|---|---|---|---|
| Suitable materials | HDPE LDPE LLDPE BIODEGRADABLE EVA | ||
| Max film width | 550mm | 750mm | 1000mm |
| Roller width | 700mm | 900mm | 1200mm |
| Film Thickness(mm) | 0.01-0.1 | 0.01-0.1 | 0.01-0.1 |
| Max.Extrusion Output | 80kg | 100kg | 120kg |
| Machine outside( m) | 5X2.2X5.5 | 5X2.4X5.5 | 5.5X2.8X6 |
| Screw Diameter(mm） | 50X2 | 55X2 | 60X2 |
| Screw L/D | 30:1 | 30:1 | 30:1 |
The AB double-layer co-extrusion system utilizes two extruders to separately process virgin PE surface material and recycled core material, combining them in a precision die to produce high-quality, cost-effective composite film.
YB series ABA three-layer film blowing machine utilizes dual extruders to produce symmetrical A/B/A structure films with virgin surface layers and recycled core material, delivering high performance at optimized cost.
YB series three-layer co-extrusion blown film machine produces high-performance films using different polymer combinations, offering both premium quality and cost efficiency for specialized applications.
