YB series ABA three-layer film blowing machine utilizes dual extruders to produce symmetrical A/B/A structure films with virgin surface layers and recycled core material, delivering high performance at optimized cost.
| Film Thickness(mm): | 0.01~0.08 |
| Max. Output(kg/h): | 80/100/120 |
| Film Layer: | 3 |
The ABA blown film machine is an advanced multi-layer co-extrusion plastic film production equipment. It uses a unique 'two extruders, three-layer structure' design, where two different raw materials are melted and plasticized through a precision die head, ultimately forming an A-B-A symmetrical film tube. After blowing, cooling, and drawing, it becomes the finished film.
Cost Reduction: High B-layer filling directly saves the use of expensive resin.
Excellent Performance: The film has a good overall feel, high hardness (good stiffness), strong tensile strength, and good brightness.
Increased Productivity: The filler has good fluidity, which helps improve production speed.
Main Applications: Widely used in the production of environmentally friendly vest bags, shopping bags, garbage bags, and various industrial packaging films.
| Main motor | Chinese Brand And Siemens |
| Suitable materials | HDPE, LDPE, LLDPE |
| Screw L/D | 32:1 / 30:1 |
| Inverter | Delta Chinese Brand |
| Temperature-controlled meter | Omron |
| Air ring | Double vent air ring |
| Model | YB-700 | YB-900 | YB-1200 |
|---|---|---|---|
| Suitable materials | HDPE LDPE LLDPE BIODEGRADABLE EVA | ||
| Max film width | 550mm | 750mm | 1000mm |
| Roller width | 700mm | 900mm | 1200mm |
| Film Thickness(mm) | 0.01-0.1 | 0.01-0.1 | 0.01-0.1 |
| Max.Extrusion Output | 80kg | 100kg | 120kg |
| Machine outside( m) | 5X2.2X5.5 | 5X2.4X5.5 | 5.5X2.8X6 |
| Screw Diameter(mm） | 50X2 | 55X2 | 60X2 |
| Screw L/D | 30:1 | 30:1 | 30:1 |
The AB double-layer co-extrusion system utilizes two extruders to separately process virgin PE surface material and recycled core material, combining them in a precision die to produce high-quality, cost-effective composite film.
The fully automatic ABA blown film machine enables unmanned intelligent production from feeding to winding, ensuring superior film quality while eliminating manual labor and efficiency bottlenecks.
YB series ABA three-layer film blowing machine utilizes dual extruders to produce symmetrical A/B/A structure films with virgin surface layers and recycled core material, delivering high performance at optimized cost.
